eforthink Lightweight and Multi-functional Positioning Tag
Advantages
Features
Parameters
Application
Core Technical Advantages
● RTLS-Based Precision: Achieves centimeter-level accuracy using UWB positioning technology and advanced signal processing.
● Robust Anti-Multipath Performance: Ensures stable and reliable positioning in complex indoor and outdoor environments.
● Two-Way Communication System: Enables instant alerts for hazards, geofence violations, and system-initiated commands.
● IP68 Protection: Dustproof, waterproof, and designed for harsh industrial environments.
● Interactive SOS Button: One-touch emergency reporting to RTLS systems for rapid response.
● Active Hazard Proximity Detection: Provides vibration and LED alerts when approaching hazardous zones.
● Built-in Barometer: Enables altitude measurement for multi-floor positioning accuracy.
Product Features
-
-
● SOS Emergency: Triple-press SOS button to broadcast distress signals to the RTLS system, accompanied by red LED flashing and vibration feedback (3 cycles).
● Paging & Evacuation Alerts: Provides LED and vibration notifications for incoming alerts, lasting 60 seconds or until manually dismissed.
● Real-Time Safety Warnings: Triggers alerts for unauthorized access, loitering, overcrowding, or hazard proximity, integrated with RTLS systems for instant incident logging.
● Low Battery Reminder: Dual LED flashing every 5 seconds when battery level is ≤10%.
● Charging Status: Breathing LED during charging; solid red LED when fully charged.
● Firmware Upgrades: LED indicators show update progress during firmware transmission.
● RFID Compatibility: Supports RFID integration for access control within RTLS environments.
Product Parameters
|
Product Dimensions |
88×58×8mm |
|
Positioning Technology |
UWB+AOA/Beacon |
|
Charging Interface |
Pogo Pin-4 (magnetic charging) |
|
Battery Type |
Lithium polymer battery |
|
Battery Capacity |
930mAh |
|
Charging/Power Supply Voltage/Current |
5V/270mA |
|
Positioning Wireless Standard |
802.15.4 2011UWB |
|
Function Configuration |
SOS Button, Multi-mode Alerts (Sound/Vibration/LED), Low-Battery Reminder, RFID Compatibility |
Application Scenarios
-
Attendance Management
Automates workforce tracking via RTLS-based systems, generating attendance reports and precisely monitoring working hours.
-
Zone Control
Implements geofencing to isolate hazardous areas. Triggers alerts for unauthorized entry or boundary violations. -
Behavioral Monitoring
Detects and alerts abnormal activities such as overcrowding or overtime stays, enabling rapid corrective actions through location-based intelligence.
